Product description:
Product Description
Spherical roller bearings are double row, self-retaining units comprising solid outer ring with a concave raceway, solid inner rings and barrel rollers with cages. The inner rings with cylingdrical or tapered bores. The symmetrical barrel rollers freely align themselves to the concave outer ring raceway. As a result, shaft deflectiongs and mislignments of the bearing seats are compensated.
Model: 20000 CC/CCK/CC W33/CCK W33/CCK MB/CA/CAK
+H0000/CCK W33+H0000 series
Material: Gcr15, chrome Steel,
Precision: P0--P5
Clearance: C0-C3
Cage: Brass/Steel
F, some data for your better reference:
| type | d | D | limited speed | limited speed | weight.kg | |
| 22205CA/W33 | 25 | 52 | 18 | 7700 | 9600 | 0.2 |
| 21305CA/W33 | 25 | 62 | 17 | 7000 | 8700 | 0.3 |
| 22206CA/W33 | 30 | 62 | 20 | 6600 | 8100 | 0.3 |
| 21306CA/W33 | 30 | 72 | 19 | 6200 | 7600 | 0.4 |
| 22207CA/W33 | 35 | 72 | 23 | 5900 | 7200 | 0.5 |
| 21307CA/W33 | 35 | 80 | 21 | 5600 | 6900 | 0.5 |
| 22208CA/W33 | 40 | 80 | 23 | 5100 | 6300 | 0.6 |
| 22208CA/W33 | 40 | 80 | 23 | 5200 | 6400 | 0.6 |
| 21308CA/W33 | 40 | 90 | 23 | 5100 | 6200 | 0.7 |
| 22308CA/W33 | 40 | 90 | 33 | 4900 | 5800 | 1.1 |
| 22308CA/W33 | 40 | 90 | 33 | 4900 | 5800 | 1.1 |
| 22209CA/W33 | 45 | 85 | 23 | 4700 | 5700 | 0.6 |
| 22209CA/W33 | 45 | 85 | 23 | 4700 | 5800 | 0.6 |
| 21309CA/W33 | 45 | 100 | 25 | 4600 | 5700 | 0.9 |
| 22309CA/W33 | 45 | 100 | 36 | 4500 | 5300 | 1.4 |
| 22309CA/W33 | 45 | 100 | 36 | 4500 | 5300 | 1.4 |
| 22210CA/W33 | 50 | 90 | 23 | 4300 | 5200 | 0.6 |
| 22210CA/W33 | 50 | 90 | 23 | 4300 | 5300 | 0.6 |
| 22310CA/W33 | 50 | 110 | 40 | 4200 | 4900 | 1.9 |
| 22310CA/W33 | 50 | 110 | 40 | 4200 | 4900 | 1.9 |
| 22211CA/W33 | 55 | 100 | 25 | 4000 | 4800 | 0.9 |
| 22311CA/W33 | 55 | 120 | 43 | 3900 | 4700 | 2.4 |
| 22311CA/W33 | 55 | 120 | 43 | 3900 | 4700 | 2.4 |
| 21311CA/W33 | 55 | 120 | 29 | 4000 | 4800 | 1.5 |
| 22212CA/W33 | 60 | 110 | 28 | 3800 | 4600 | 1.2 |
| 22212CA/W33 | 60 | 110 | 28 | 3800 | 4700 | 1.2 |
| 22312CA/W33 | 60 | 130 | 46 | 3600 | 4300 | 3 |
| 22312CA/W33 | 60 | 130 | 46 | 3600 | 4300 | 3 |
| 21312CA/W33 | 60 | 130 | 31 | 3700 | 4600 | 1.9 |
| 22213CA/W33 | 65 | 120 | 31 | 3600 | 4400 | 1.6 |
| 22213CA/W33 | 65 | 120 | 31 | 3600 | 4400 | 1.6 |
| 21313CA/W33 | 65 | 140 | 33 | 3500 | 4300 | 2.4 |
| 22313CA/W33 | 65 | 140 | 48 | 3400 | 4100 | 3.6 |
| 22313CA/W33 | 65 | 140 | 48 | 3400 | 4100 | 3.6 |
| 22214CA/W33 | 70 | 125 | 31 | 3400 | 4100 | 1.6 |
| 22314CA/W33 | 70 | 150 | 51 | 3200 | 3800 | 4.4 |
| 21314CA/W33 | 70 | 150 | 35 | 3300 | 4100 | 2.9 |
| 22314CA/W33 | 70 | 150 | 51 | 3200 | 3800 | 4.4 |
| 22215CA/W33 | 75 | 130 | 31 | 3200 | 3900 | 1.7 |
| 22315CA/W33 | 75 | 160 | 55 | 3100 | 3600 | 5.4 |
| 21315CA/W33 | 75 | 160 | 37 | 3200 | 3800 | 3.5 |
| 22315CA/W33 | 75 | 160 | 55 | 3100 | 3600 | 5.4 |
| 22216CA/W33 | 80 | 140 | 33 | 3000 | 3700 | 2.2 |
| 22216CA/W33 | 80 | 140 | 33 | 3000 | 3700 | 2.2 |
| 21316CA/W33 | 80 | 170 | 39 | 3000 | 3700 | 4.1 |
| 22316CA/W33 | 80 | 170 | 58 | 2900 | 3500 | 6.4 |
| 22316CA/W33 | 80 | 170 | 58 | 2900 | 3500 | 6.4 |
| 22217CA/W33 | 85 | 150 | 36 | 2900 | 3500 | 2.7 |
| 22217CA/W33 | 85 | 150 | 36 | 2900 | 3600 | 2.7 |
| 21317CA/W33 | 85 | 180 | 41 | 2900 | 3500 | 5.2 |
| 22317CA/W33 | 85 | 180 | 60 | 2700 | 3200 | 7.5 |
| 22317CA/W33 | 85 | 180 | 60 | 2700 | 3200 | 7.5 |
| 22218CA/W33 | 90 | 160 | 40 | 2800 | 3400 | 3.5 |
| 22218CA/W33 | 90 | 160 | 40 | 2800 | 3400 | 3.5 |
| 23218CA/W33 | 90 | 160 | 52 | 2300 | 2700 | 4.5 |
| 23218CA/W33 | 90 | 160 | 52 | 2300 | 2700 | 4.5 |
| 22318CA/W33 | 90 | 190 | 64 | 2600 | 3000 | 8.8 |
| 22318CA/W33 | 90 | 190 | 64 | 2600 | 3000 | 8.8 |
| 21318CA/W33 | 90 | 190 | 43 | 2800 | 3300 | 6 |
| 22319CA/W33 | 90 | 190 | 64 | 2600 | 3000 | 8.8 |
| 23318CA/W33 | 90 | 190 | 73 | 1900 | 2200 | 10.1 |
| 22219CA/W33 | 95 | 170 | 43 | 2800 | 3400 | 4.2 |
| 22219CA/W33 | 95 | 170 | 43 | 2800 | 3400 | 4.2 |
| 22319CA/W33 | 95 | 200 | 67 | 2400 | 2800 | 10.2 |
| 23120CA/W33 | 100 | 165 | 52 | 2400 | 2800 | 4.4 |
| 22220CA/W33 | 100 | 180 | 46 | 2700 | 3200 | 5.1 |
| 22220CA/W33 | 100 | 180 | 46 | 2700 | 3200 | 5.1 |
| 23220CA/W33 | 100 | 180 | 60.3 | 2100 | 2500 | 6.6 |
| 23220CA/W33 | 100 | 180 | 60.3 | 2100 | 2500 | 6.6 |
| 22320CA/W33 | 100 | 215 | 73 | 2300 | 2700 | 13 |
| 22320CA/W33 | 100 | 215 | 73 | 2300 | 2700 | 13 |
| 23122CA/W33 | 110 | 180 | 56 | 2200 | 2600 | 5.6 |
| 23122CA/W33 | 110 | 180 | 56 | 2200 | 2600 | 5.6 |
| 24122CA/W33 | 110 | 180 | 69 | 1800 | 2100 | 6.9 |
| 22222CA/W33 | 110 | 200 | 53 | 2500 | 3000 | 7.3 |
| 22222CA/W33 | 110 | 200 | 53 | 2500 | 3000 | 7.3 |
| 23222CA/W33 | 110 | 200 | 69.8 | 1900 | 2200 | 9.6 |
| 23222CA/W33 | 110 | 200 | 69.8 | 1900 | 2200 | 9.6 |
| 22322CA/W33 | 110 | 240 | 80 | 2000 | 2300 | 18 |
| 22322CA/W33 | 110 | 240 | 80 | 2000 | 2300 | 18 |
| 23322CA/W33 | 110 | 240 | 92.1 | 1500 | 1700 | 20.7 |
| 23024CA/W33 | 120 | 180 | 46 | 2300 | 2900 | 4.1 |
| 24024CA/W33 | 120 | 180 | 60 | 2000 | 2400 | 5.3 |
| 23124CA/W33 | 120 | 200 | 62 | 2000 | 2300 | 7.8 |
| 23124CA/W33 | 120 | 200 | 62 | 2000 | 2300 | 7.8 |
| 24124CA/W33 | 120 | 200 | 80 | 1600 | 1800 | 10.1 |
| 22224CA/W33 | 120 | 215 | 58 | 2400 | 2900 | 9.1 |
| 22224CA/W33 | 120 | 215 | 58 | 2400 | 2900 | 9.1 |
| 23224CA/W33 | 120 | 215 | 76 | 1700 | 2000 | 12 |
| 22324CA/W33 | 120 | 260 | 86 | 1800 | 2100 | 22.6 |
| 22324CA/W33 | 120 | 260 | 86 | 1800 | 2100 | 22.6 |
| 23324CA/W33 | 120 | 260 | 106 | 1300 | 1400 | 27.8 |
| 23926CA/W33 | 130 | 180 | 37 | 2000 | 2500 | 2.8 |
| 23026CA/W33 | 130 | 200 | 52 | 2200 | 2700 | 5.9 |
| 24026CA/W33 | 130 | 200 | 69 | 1900 | 2200 | 7.9 |
| 23126CA/W33 | 130 | 210 | 64 | 1800 | 2100 | 8.6 |
| 23126CA/W33 | 130 | 210 | 64 | 1800 | 2100 | 8.6 |
| 24126CA/W33 | 130 | 210 | 80 | 1500 | 1700 | 10.7 |
| 22226CA/W33 | 130 | 230 | 64 | 2200 | 2600 | 11.4 |
| 22226CA/W33 | 130 | 230 | 64 | 2200 | 2600 | 11.4 |
| 23226CA/W33 | 130 | 230 | 80 | 1600 | 1800 | 14 |
| 22326CA/W33 | 130 | 280 | 93 | 1700 | 1900 | 28.2 |
| 22326CA/W33 | 130 | 280 | 93 | 1700 | 1900 | 28.2 |
| 23326CA/W33 | 130 | 280 | 112 | 1200 | 1300 | 34 |
| 23928CA/W33 | 140 | 190 | 37 | 1900 | 2300 | 3 |
| 23028CA/W33 | 140 | 210 | 53 | 2000 | 2500 | 6.4 |
| 24028CA/W33 | 140 | 210 | 69 | 1700 | 2000 | 8.3 |
| 23128CA/W33 | 140 | 225 | 68 | 1700 | 2000 | 10 |
| 24128CA/W33 | 140 | 225 | 85 | 1300 | 1500 | 13 |
| 26228CA/W33 | 140 | 240 | 80 | 1200 | 1400 | 14.7 |
| 22228CA/W33 | 140 | 250 | 68 | 2000 | 2400 | 14.4 |
| 22228CA/W33 | 140 | 250 | 68 | 2000 | 2400 | 14.4 |
| 22328CA/W33 | 140 | 300 | 102 | 1500 | 1700 | 35.4 |
| 22328CA/W33 | 140 | 300 | 102 | 1500 | 1700 | 35.4 |
| 23328CA/W33 | 140 | 300 | 118 | 1000 | 1100 | 41 |
| 23030CA/W33 | 150 | 225 | 56 | 1900 | 2300 | 7.8 |
| 24030CA/W33 | 150 | 225 | 75 | 1600 | 1900 | 10.4 |
| 23130CA/W33 | 150 | 250 | 80 | 1500 | 1700 | 16 |
| 24130CA/W33 | 150 | 250 | 100 | 1200 | 1300 | 19.7 |
| 22230CA/W33 | 150 | 270 | 73 | 1800 | 2200 | 18.2 |
| 22230CA/W33 | 150 | 270 | 73 | 1800 | 2100 | 18 |
| 23230CA/W33 | 150 | 270 | 96 | 1300 | 1500 | 24 |
| 22330CA/W33 | 150 | 320 | 108 | 1400 | 1600 | 42.6 |
| 22330CA/W33 | 150 | 320 | 108 | 1400 | 1600 | 42.6 |
| 23330CA/W33 | 150 | 320 | 128 | 960 | 1100 | 50.4 |
| below item only have CA AND MB cage | ||||||
| 23932CA/W33 | 160 | 220 | 45 | 1800 | 2100 | 5.1 |
| 23032CA/W33 | 160 | 240 | 60 | 1700 | 2100 | 9.4 |
| 24032CA/W33 | 160 | 240 | 80 | 1500 | 1800 | 12.6 |
| 23132CA/W33 | 160 | 270 | 86 | 1400 | 1600 | 20.1 |
| 22232CA/W33 | 160 | 290 | 80 | 1700 | 2000 | 23.1 |
| 23232CA/W33 | 160 | 290 | 104 | 1200 | 1400 | 30 |
| 22332CA/W33 | 160 | 340 | 114 | 1300 | 1500 | 50.6 |
| 22332CA/W33 | 160 | 340 | 114 | 1300 | 1500 | 50.6 |
| 23332CA/W33 | 160 | 340 | 136 | 850 | 940 | 60.4 |
| 23934CA/W33 | 170 | 230 | 45 | 1600 | 2000 | 5.3 |
| 23034CA/W33 | 170 | 260 | 67 | 1600 | 1900 | 12.8 |
| 24034CA/W33 | 170 | 260 | 90 | 1300 | 1600 | 17.2 |
| 23134CA/W33 | 170 | 280 | 88 | 1300 | 1500 | 21.5 |
| 24134CA/W33 | 170 | 280 | 109 | 980 | 1100 | 26.6 |
| 22234CA/W33 | 170 | 310 | 86 | 1600 | 1900 | 28.5 |
| 23234CA/W33 | 170 | 310 | 110 | 1100 | 1200 | 36.5 |
| 23036CA/W33 | 180 | 280 | 74 | 1500 | 1800 | 17 |
| 24036CA/W33 | 180 | 280 | 100 | 1200 | 1500 | 23 |
| 23136CA/W33 | 180 | 300 | 96 | 1200 | 1400 | 27 |
| 24136CA/W33 | 180 | 300 | 118 | 920 | 1000 | 33 |
| 22236CA/W33 | 180 | 320 | 86 | 1500 | 1700 | 30 |
| 23236CA/W33 | 180 | 320 | 112 | 1000 | 1200 | 39 |
| 22336CA/W33 | 180 | 380 | 126 | 1100 | 1200 | 69 |
| 23938CA/W33 | 190 | 260 | 52 | 1400 | 1700 | 8.1 |
| 23038CA/W33 | 190 | 290 | 75 | 1400 | 1700 | 18 |
| 24038CA/W33 | 190 | 290 | 100 | 1200 | 1400 | 24 |
| 23138CA/W33 | 190 | 320 | 104 | 1100 | 1300 | 34 |
| 24138CA/W33 | 190 | 320 | 128 | 860 | 950 | 42 |
| 22238CA/W33 | 190 | 340 | 92 | 1400 | 1600 | 36 |
| 23238CA/W33 | 190 | 340 | 120 | 960 | 1100 | 47 |
| 22338CA/W33 | 190 | 400 | 132 | 1000 | 1200 | 80 |
| 23940CA/W33 | 200 | 280 | 60 | 1400 | 1600 | 11 |
| 23040CA/W33 | 200 | 310 | 82 | 1300 | 1600 | 23 |
| 24040CA/W33 | 200 | 310 | 109 | 1100 | 1300 | 30 |
| 23140CA/W33 | 200 | 340 | 112 | 1100 | 1200 | 42 |
| 23140CA/W33 | 200 | 340 | 112 | 1100 | 1200 | 42 |
| 24140CA/W33 | 200 | 340 | 140 | 750 | 830 | 52 |
| 22240CA/W33 | 200 | 360 | 98 | 1300 | 1500 | 43 |
| 23240CA/W33 | 200 | 360 | 128 | 890 | 1000 | 56 |
| 26340CA/W33 | 200 | 380 | 126 | 700 | 780 | 65.8 |
| 22340CA/W33 | 200 | 420 | 138 | 970 | 1100 | 93 |
| 23340CA/W33 | 200 | 420 | 165 | 640 | 700 | 111 |
| 23944CA/W33 | 220 | 300 | 60 | 1200 | 1500 | 12 |
| 23044CA/W33 | 220 | 340 | 90 | 1200 | 1400 | 30 |
| 24044CA/W33 | 220 | 340 | 118 | 930 | 1100 | 39 |
| 23144CA/W33 | 220 | 370 | 120 | 940 | 1100 | 52 |
| 23144CA/W33 | 220 | 370 | 120 | 940 | 1100 | 52 |
| 24144CA/W33 | 220 | 370 | 150 | 690 | 760 | 65 |
| 22244CA/W33 | 220 | 400 | 108 | 1200 | 1400 | 59 |
| 23244CA/W33 | 220 | 400 | 144 | 780 | 870 | 79 |
| 26344CA/W33 | 220 | 420 | 138 | 610 | 680 | 88.2 |
| 22344CA/W33 | 220 | 460 | 145 | 840 | 950 | 116 |
| 23344CA/W33 | 220 | 460 | 180 | 560 | 610 | 145 |
| 23948CA/W33 | 240 | 320 | 60 | 1100 | 1300 | 13 |
| 23048CA/W33 | 240 | 360 | 92 | 1100 | 1300 | 33 |
| 24048CA/W33 | 240 | 360 | 118 | 850 | 980 | 42 |
| 23148CA/W33 | 240 | 400 | 128 | 850 | 970 | 65 |
| 24148CA/W33 | 240 | 400 | 160 | 580 | 640 | 81 |
| 22248CA/W33 | 240 | 440 | 120 | 1000 | 1200 | 80 |
| 23248CA/W33 | 240 | 440 | 160 | 680 | 760 | 107 |
| 26348CA/W33 | 240 | 460 | 147 | 550 | 610 | 113 |
| 22348CA/W33 | 240 | 500 | 155 | 760 | 850 | 147 |
| 23348CA/W33 | 240 | 500 | 195 | 500 | 540 | 185 |
| 26250CA/W33 | 250 | 410 | 128 | 580 | 650 | 64 |
| 23952CA/W33 | 260 | 360 | 75 | 1000 | 1200 | 23 |
| 23052CA/W33 | 260 | 400 | 104 | 990 | 1200 | 47 |
| 23052CA/W33 | 260 | 400 | 104 | 990 | 1200 | 47 |
| 24052CA/W33 | 260 | 400 | 140 | 750 | 860 | 64 |
| 23152CA/W33 | 260 | 440 | 144 | 760 | 860 | 89 |
| 24152CA/W33 | 260 | 440 | 180 | 530 | 570 | 112 |
| 22252CA/W33 | 260 | 480 | 130 | 910 | 1100 | 104 |
| 23252CA/W33 | 260 | 480 | 174 | 610 | 680 | 139 |
| 22352CA/W33 | 260 | 540 | 165 | 680 | 770 | 182 |
| 23352CA/W33 | 260 | 540 | 206 | 450 | 480 | 227 |
| 23956CA/W33 | 280 | 380 | 75 | 920 | 1100 | 24 |
| 23056CA/W33 | 280 | 420 | 106 | 930 | 1100 | 51 |
| 24056CA/W33 | 280 | 420 | 140 | 690 | 790 | 68 |
| 23156CA/W33 | 280 | 460 | 146 | 710 | 800 | 96 |
| 24156CA/W33 | 280 | 460 | 180 | 490 | 530 | 118 |
| 22256CA/W33 | 280 | 500 | 130 | 850 | 990 | 110 |
| 23256CA/W33 | 280 | 500 | 176 | 560 | 620 | 149 |
| 22356CA/W33 | 280 | 580 | 175 | 620 | 690 | 222 |
| 23356CA/W33 | 280 | 580 | 224 | 400 | 430 | 284 |
| 23960CA/W33 | 300 | 420 | 90 | 840 | 1000 | 38 |
| 23060CA/W33 | 300 | 460 | 118 | 830 | 980 | 71 |
| 24060CA/W33 | 300 | 460 | 160 | 620 | 700 | 96 |
| 23160CA/W33 | 300 | 500 | 160 | 630 | 710 | 126 |
| 24160CA/W33 | 300 | 500 | 200 | 430 | 460 | 158 |
| 22260CA/W33 | 300 | 540 | 140 | 770 | 890 | 139 |
| 23260CA/W33 | 300 | 540 | 192 | 510 | 560 | 191 |
| 23964CA/W33 | 320 | 440 | 90 | 780 | 930 | 40 |
| 23064CA/W33 | 320 | 480 | 121 | 780 | 910 | 76 |
| 24064CA/W33 | 320 | 480 | 160 | 580 | 660 | 101 |
| 23164CA/W33 | 320 | 540 | 176 | 580 | 650 | 164 |
| 24164CA/W33 | 320 | 540 | 218 | 380 | 410 | 203 |
| 22264CA/W33 | 320 | 580 | 150 | 710 | 820 | 173 |
| 23264CA/W33 | 320 | 580 | 208 | 460 | 510 | 240 |
| 23968CA/W33 | 340 | 460 | 90 | 730 | 860 | 43 |
| 23068CA/W33 | 340 | 520 | 133 | 710 | 830 | 101 |
| 24068CA/W33 | 340 | 520 | 180 | 530 | 600 | 137 |
| 23168CA/W33 | 340 | 580 | 190 | 530 | 590 | 206 |
| 24168CA/W33 | 340 | 580 | 243 | 340 | 370 | 264 |
| 23268CA/W33 | 340 | 620 | 224 | 420 | 460 | 296 |
| 23972CA/W33 | 360 | 480 | 90 | 680 | 810 | 45 |
| 23072CA/W33 | 360 | 540 | 134 | 680 | 800 | 107 |
| 24072CA/W33 | 360 | 540 | 180 | 500 | 560 | 144 |
| 23172CA/W33 | 360 | 600 | 192 | 500 | 560 | 218 |
| 24172CA/W33 | 360 | 600 | 243 | 320 | 340 | 276 |
| 23272CA/W33 | 360 | 650 | 232 | 400 | 430 | 334 |
| 23976CA/W33 | 380 | 520 | 106 | 640 | 750 | 66 |
| 23076CA/W33 | 380 | 560 | 135 | 630 | 740 | 112 |
| 24076CA/W33 | 380 | 560 | 180 | 470 | 530 | 150 |
| 23176CA/W33 | 380 | 620 | 194 | 470 | 530 | 229 |
| 24176CA/W33 | 380 | 620 | 243 | 300 | 320 | 287 |
| 23276CA/W33 | 380 | 680 | 240 | 370 | 400 | 376 |
| 23980CA/W33 | 400 | 540 | 106 | 600 | 720 | 69 |
| 23080CA/W33 | 400 | 600 | 148 | 590 | 690 | 146 |
| 24080CA/W33 | 400 | 600 | 200 | 430 | 480 | 197 |
| 23180CA/W33 | 400 | 650 | 200 | 440 | 500 | 258 |
| 24180CA/W33 | 400 | 650 | 250 | 290 | 310 | 323 |
| 23280CA/W33 | 400 | 720 | 256 | 340 | 370 | 452 |
| 22380CA/W33 | 400 | 820 | 243 | 390 | 430 | 613 |
| 23984CA/W33 | 420 | 560 | 106 | 570 | 670 | 72 |
| 23084CA/W33 | 420 | 620 | 150 | 560 | 650 | 154 |
| 24084CA/W33 | 420 | 620 | 200 | 410 | 460 | 205 |
| 23184CA/W33 | 420 | 700 | 224 | 410 | 450 | 346 |
| 24184CA/W33 | 420 | 700 | 280 | 260 | 280 | 432 |
| 23284CA/W33 | 420 | 760 | 272 | 320 | 350 | 537 |
| 23988CA/W33 | 440 | 600 | 118 | 530 | 630 | 97 |
| 23088CA/W33 | 440 | 650 | 157 | 520 | 610 | 177 |
| 24088CA/W33 | 440 | 650 | 212 | 380 | 430 | 239 |
| 23188CA/W33 | 440 | 720 | 226 | 380 | 430 | 361 |
| 24188CA/W33 | 440 | 720 | 280 | 250 | 260 | 448 |
| 23288CA/W33 | 440 | 790 | 280 | 300 | 320 | 593 |
| 23992CA/W33 | 460 | 620 | 118 | 520 | 620 | 101 |
| 23092CA/W33 | 460 | 680 | 163 | 500 | 570 | 202 |
| 24092CA/W33 | 460 | 680 | 218 | 360 | 410 | 270 |
| 23192CA/W33 | 460 | 760 | 240 | 370 | 410 | 433 |
| 24192CA/W33 | 460 | 760 | 300 | 220 | 240 | 542 |
| 23292CA/W33 | 460 | 830 | 296 | 280 | 310 | 697 |
| 23996CA/W33 | 480 | 650 | 128 | 500 | 590 | 121 |
| 23096CA/W33 | 480 | 700 | 165 | 470 | 550 | 211 |
| 24096CA/W33 | 480 | 700 | 218 | 340 | 380 | 279 |
| 23196CA/W33 | 480 | 790 | 248 | 340 | 370 | 482 |
| 24196CA/W33 | 480 | 790 | 308 | 210 | 220 | 598 |
| 23296CA/W33 | 480 | 870 | 310 | 250 | 270 | 805 |
| 239/500CA/W33 | 500 | 670 | 128 | 470 | 560 | 126 |
| 230/500CA/W33 | 500 | 720 | 167 | 460 | 530 | 221 |
| 240/500CA/W33 | 500 | 720 | 218 | 330 | 370 | 289 |
| 231/500CA/W33 | 500 | 830 | 264 | 320 | 350 | 572 |
| 241/500CA/W33 | 500 | 830 | 325 | 200 | 210 | 704 |
| 232/500CA/W33 | 500 | 920 | 336 | 240 | 260 | 988 |
| 239/530CA/W33 | 530 | 710 | 136 | 430 | 500 | 149 |
| 230/530CA/W33 | 530 | 780 | 185 | 420 | 480 | 299 |
| 240/530CA/W33 | 530 | 780 | 250 | 300 | 330 | 403 |
| 231/530CA/W33 | 530 | 870 | 272 | 300 | 320 | 637 |
| 241/530CA/W33 | 530 | 870 | 335 | 180 | 190 | 785 |
| 232/530CA/W33 | 530 | 980 | 355 | 220 | 240 | 1190 |
| 239/560CA/W33 | 560 | 750 | 140 | 400 | 470 | 172 |
| 230/560CA/W33 | 560 | 820 | 195 | 390 | 450 | 344 |
| 240/560CA/W33 | 560 | 820 | 258 | 280 | 310 | 456 |
| 231/560CA/W33 | 560 | 920 | 280 | 270 | 300 | 734 |
| 241/560CA/W33 | 560 | 920 | 355 | 160 | 170 | 931 |
| 232/560CA/W33 | 560 | 1030 | 365 | 200 | 220 | 1340 |
| 239/600CA/W33 | 600 | 800 | 150 | 370 | 430 | 207 |
| 230/600CA/W33 | 600 | 870 | 200 | 360 | 410 | 391 |
| 240/600CA/W33 | 600 | 870 | 272 | 260 | 280 | 531 |
| 231/600CA/W33 | 600 | 980 | 300 | 250 | 270 | 887 |
| 239/630CA/W33 | 630 | 850 | 165 | 340 | 400 | 264 |
| 230/630CA/W33 | 630 | 920 | 212 | 330 | 380 | 469 |
| 240/630CA/W33 | 630 | 920 | 290 | 240 | 260 | 642 |
| 231/630CA/W33 | 630 | 1030 | 315 | 230 | 250 | 1030 |
| 241/630CA/W33 | 630 | 1030 | 400 | 140 | 140 | 1310 |
| 239/670CA/W33 | 670 | 900 | 170 | 320 | 370 | 302 |
| 230/670CA/W33 | 670 | 980 | 230 | 310 | 350 | 579 |
| 240/670CA/W33 | 670 | 980 | 308 | 220 | 240 | 775 |
| 231/670CA/W33 | 670 | 1090 | 336 | 210 | 230 | 1220 |
| 241/670CA/W33 | 670 | 1090 | 412 | 130 | 130 | 1500 |
| 232/670CA/W33 | 670 | 1220 | 438 | 160 | 170 | 2240 |
| 239/710CA/W33 | 710 | 950 | 180 | 300 | 340 | 353 |
| 230/710CA/W33 | 710 | 1030 | 236 | 290 | 330 | 647 |
| 240/710CA/W33 | 710 | 1030 | 315 | 200 | 220 | 863 |
| 231/710CA/W33 | 710 | 1150 | 345 | 200 | 210 | 1390 |
| 241/710CA/W33 | 710 | 1150 | 438 | 120 | 120 | 1760 |
| 239/750CA/W33 | 750 | 1000 | 185 | 280 | 320 | 398 |
| 230/750CA/W33 | 750 | 1090 | 250 | 270 | 300 | 770 |
| 240/750CA/W33 | 750 | 1090 | 335 | 190 | 200 | 1030 |
| 241/750CA/W33 | 750 | 1220 | 475 | 110 | 110 | 2170 |
| 239/800CA/W33 | 800 | 1060 | 195 | 270 | 310 | 465 |
| 230/800CA/W33 | 800 | 1150 | 258 | 250 | 280 | 868 |
| 240/800CA/W33 | 800 | 1150 | 345 | 170 | 190 | 1160 |
| 231/800CA/W33 | 800 | 1280 | 365 | 160 | 180 | 1800 |
| 241/800CA/W33 | 800 | 1280 | 475 | 97 | 100 | 2340 |
| 232/800CA/W33 | 800 | 1420 | 488 | 120 | 130 | 3310 |
| 238/850CA/W33 | 850 | 1030 | 136 | 130 | 150 | 233 |
| 239/850CA/W33 | 850 | 1120 | 200 | 250 | 290 | 525 |
| 230/850CA/W33 | 850 | 1220 | 272 | 230 | 260 | 1030 |
| 240/850CA/W33 | 850 | 1220 | 365 | 160 | 170 | 1380 |
| 231/850CA/W33 | 850 | 1360 | 400 | 150 | 160 | 2220 |
| 232/850CA/W33 | 850 | 1500 | 515 | 110 | 120 | 3880 |
| 239/900CA/W33 | 900 | 1180 | 206 | 220 | 250 | 592 |
| 230/900CA/W33 | 900 | 1280 | 280 | 210 | 240 | 1140 |
| 240/900CA/W33 | 900 | 1280 | 375 | 150 | 160 | 1530 |
| 231/900CA/W33 | 900 | 1420 | 412 | 140 | 150 | 2450 |
| 241/900CA/W33 | 900 | 1420 | 515 | 82 | 85 | 3060 |
| 232/900CA/W33 | 900 | 1580 | 515 | 100 | 110 | 4280 |
| 239/950CA/W33 | 950 | 1250 | 224 | 210 | 240 | 729 |
| 230/950CA/W33 | 950 | 1360 | 300 | 200 | 230 | 1400 |
| 240/950CA/W33 | 950 | 1360 | 412 | 130 | 140 | 1920 |
| 231/950CA/W33 | 950 | 1500 | 438 | 130 | 140 | 2910 |
Company information:
XSY bearing Co., Ltd. has its own factory. We make sure to offer you the most competitive price.
XSY bearing Co., Ltd. has a professional R&D team and an after-sale team, so what you buy is top-end, and what you use is quality & service guaranteed.
XSY bearing Co., Ltd. is a bearing manufacturer since 1990. Rich experience makes us more professional.
The bearing is long durability, high speed and low noise.
OEM & ODM are available. The products have passed ISO9001-2008 certification.
All kinds of bearing simples are available.
Package:
FAQ
Q1: How is your quality ?
A1:Good quality. ISO9001:2008 certificate to ensure the quality.
Q2: Can you privide free samples?
A2: Sample is free (except large bearings),and postage should be paid by buyer. But postage can be refund after order is confirmed.
Q3: What's your brand and service?
A3: We have our own brand in China with brand SPD
A3: We supply OEM service and after sales service
Q4: What is the Warranty for the bearings?
A4: For the bearings,we have 1 years warranty. If any quality problems on our side occured in this period ,we will take on the shipping cost and replacement.
Q5: Is there any cheap shipping cost to import to our country?
A5: For small order,express will be best.And for bulk order,sea ship way is best but take much time.
For urgent orders,we suggest via air to airport plus our ship partner send to your door.
Q6: Can we get support if we have our own market position?
A6: Please inform us your detailed information about your market ,we will discuss and propose helpful suggestion for you and to find the best solution for you.
Contact :
